2-2. 8/16 Channel Premium DVR
The rear panels of the 6/18 channel Performance DVR look like the following:
[8 Channel Premium Model]
[16 Channel Premium Model]
• Front USB: On the front panel, two USB ports are provided to connect external devices like
HDD and Flash memory for Backup and System upgrade. A USB mouse can only be connected
to the USB port dedicated for mouse.
Video Input
Connect the coaxial cables from the cameras to the BNC video connectors.
Loop-Through Video
Connect the coaxial cables from the Loop BNC connector (Optional
accessory) to another device.
Note
: To use Loop option, additional Loop BNC connector (Optional
accessory) is needed. Please contact your supplier about this.
Audio Input
The DVR can record audio up to 8 sources. Connect the audio sources to
the Audio-In Multi-connectors (Optional Accessory). All channels need
external pre-amplifiers.
It is the user's responsibility to abide to local laws and regulations
regarding to recording audio.
