Roland SPD-S - Saving the Created Phrase as a New Wave (Phrase Resampling)

64
Chapter 5 Layering Performances to Make a Phrase (Phrase Maker)
8
Press [EXIT] to terminate Phrase Maker.
When you press [EXIT] to return to the original mode, the phrase that you have just created is lost.
To save it, execute phrase resampling explained below.
■ Saving the Created Phrase as a New Wave
(Phrase Resampling)
1
You can change the playback tempo when phrase playback is stopped
(Step 7 on p. 63). Press [-]/[+].
2
Press [RESAMPLE].
3
A “Gain” indication is displayed. Set the following parameters.
Press the PAGE buttons to change the parameter, and press [-]/[+] to change the value.
See p. 66 for details on the parameters.
• Gain
• Mode
• Grade
• Dst (Destination)
4
Press a [>] button to display “resample, sure?”
5
Press [Enter] to start phrase resampling.
While resampling is in progress, "now processing.." is displayed.
6
A “write?” indication is displayed. Assign a name to the wave. Press
the PAGE buttons to move the cursor under the name and press [-]/[+]
to change the character at the cursor position. When the name is
complete, press [ENTER] to save it.
A “now writing..” indication appears; it shows that a wave is being saved.
If you do not want to save the wave, press [EXIT], and you will return to the Gain screen in Step 3.
If you hold down [SHIFT] and
press [-]/[+], you can change
the tempo value in steps of 10.
While [FUNC] is depressed,
the remaining time for
resampling (“Remain”) is
displayed. (p. 66)
The parameters on the left are
reset to their respective initial
values when phrase
resampling is finished.
Effects are disabled during
phrase resampling.
Do not power the SPD-S off
while resampling is in
progress.
If you press [START/STOP] or
hit a relevant playing surface,
you can check the resampled
sound.
Do not power the SPD-S off
while saving a wave.
The start point (p. 47, p. 48) in the created wave is set automatically, and “MARK” lights up.
