80
Chapter 7 Changing the Setup (Overall Environment)
TRIGGER INPUT
How to make settings for pads, kick triggers or acoustic drum triggers connected to the TRIG IN jacks.
Set the following parameters. Press the PAGE buttons to change parameters and press [-]/[+] to change the value.
When InputMode is set to TRGx2, Trig Type can be set for individual playing surfaces. Hit a pad/trigger or hold down [SHIFT]
and press the PAGE buttons to change the pad/trigger. Verify with the flashing pad indicators.
Correspondence Table for Trigger Type
When you connect two pads or other devices using the PCS-31 cable, the white plug of the PCS-31 serves as TRIG IN 1 and its red
plug as TRIG IN 2.
To use the rim-shot/edge-shot/bell-shot features, connect a pad using a stereo cable that comes with the pad product. In this case,
you can connect one pad only.
When using pads or other devices from other manufacturers, the SPD-S may not produce a performance as designed even with
settings on Trig Type or trigger parameters. We recommend using Roland products for expressive performance.
Parameter Value Descriptions
InputMode
(Input
Mode)
HD&RM,
TRGx2
Select whether or not to use rim-shot.
HD&RM: To connect a single pad with rim-shot/edge-shot/bell-shot features (PD-7, PD-9,
PD-80R, PD-120, CY-6, CY-12R/C, CY-12H, CY-14C, CY-15R).
TRGx2: To connect two devices like pads and kick triggers.
* When two pads are connected, the rim-shot/edge-shot/bell-shot features are unavailable.
Type
(Trigger
Type)
PD,
PD-80/100,
PD-80R,
PD-120,
KD,
CY-6,
CY,
RT-7K,
RT-5S,
RT-3T
Select the trigger type (the type of pad or other device to be used) to ensure that the SPD-S can
accurately receive input signals from the TRIG IN jacks.
The trigger type definition leads to accurate detection of strike force, to prevention of repeated
sound production, and to compatibility with rim-shots on the PD-80R or the PD-120.
After selecting the trigger type, adjust the pad sensitivity if needed.
See “Correspondence Table for Trigger Type” below for details on the values.
* The SPD-S does NOT support the choke feature of the PD-7/9, the CY-6, the CY-12R/C, and
the CY-12H/14C/15R.
* The SPD-S does NOT support the three-way trigger feature of the CY-12R/C, and the CY-15R.
Product to be connected
Value
PD-5/6/7/9
PD
PD-80/100 PD-80/100
PD-80R PD-80R
PD-120 PD-120
KD-5/7/80/120 KD
CY-6 CY-6
CY-12R/C, CY-12H/14C/15R CY
RT-7K RT-7K
RT-5S RT-5S
RT-3T RT-3T
