Rosemount Model 3095 Multivariable
™
Level Controller
2-14
H
H
H
H
H
H
H
L
L
L
L
L
L
L
B
Controller Height = -B
A
A
B
C
D
E
M
N
Controller Height = A
or
Controller Height = -B
Controller Height = A
or
Controller Height = C
Controller Height = E + D
Controller Height = M - N
OPEN TANK
OPEN TANK
WITH BUBBLER
CLOSED TANK
WITH DRY LEG
CLOSED TANK WITH WET LEG,
CONTROLLER ABOVE BOTTOM OF TANK
CLOSED TANK WITH WET LEG,
CONTROLLER BELOW BOTTOM OF TANK
CLOSED TANK WITH WET LEG,
CONTROLLER ABOVE BOTTOM OF TANK
FIGURE 2-9. Example Installations.
3095-3095_01A
