Specifications and Reference Data
Options
Standard Configuration
Unless otherwise specified, the controller is shipped as follows:
Engineering units:
Differential inH
2
O (Range 2)
Process Temp. °F
Output Level Control
Flange type: Specified model code option
Flange material: Specified model code option
O-ring material: Specified model code option
Drain/vent: Specified model code option
Software tag: (Blank)
Software tag (8 characters maximum) is left blank unless specified.
Unless otherwise specified, the Level Controller is shipped as follows:
• Measures level of water in feet with controller height set to 0 feet.
• Control Algorithm set to reverse-acting PID control, with P=1,
and I and D terms set to 0; power-up control signal set to 0%:
target setpoint set to 50% of full scale; and mode shed action set
to go to shed output.
Fixed Process Temperature
If process temperature input code is set to 0, the desired fixed process
temperature can be specified during order entry.
Custom Configuration (Option Code C2)
If Option Code C2 is ordered, the customer specifies level parameters
and controller configuration parameters in addition to the standard
configuration parameters. Requires a completed Configuration Data
Sheet (00806-0100-4741).
Code Software Functionality
L Level Control
Code Options
CC
FA
FB
FC
FD
FP
FQ
P1
P2
Q4
Q8
C2
S1
S2
S5
DF
Autotuner
Level Flange, SST, 2 in., ANSI Class 150, Vertical Mount
Level Flange, SST, 2 in., ANSI Class 300, Vertical Mount
Level Flange, SST, 3 in., ANSI Class 150, Vertical Mount
Level Flange, SST, 3 in., ANSI Class 300, Vertical Mount
DIN Level Flange, SST, DN 50, PN 40, Vertical Mount
DIN Level Flange, SST, DN 80, PN 40, Vertical Mount
Hydrostatic Testing
Cleaning for Special Services
Inspection Certificate for Calibration Data
Material Inspection Certificate
Custom Configuration
Assembly with One Diaphragm Seal (requires diaphragm seal model number – see 00813-0100-4016)
Assembly with Two Diaphragm Seals (requires diaphragm seal model number – see 00813-0100-4016)
Assembly with Model 305 Integral Manifold (requires integral manifold model number – see 00813-0100-4733)
Plated CS
Flange Adapters — Adapter Type Determined by Selected Flange Material:
SST
Hastelloy C
Typical Model Number 3095C A 2 4 A A A 1 1 A A 0 1 1 0 L
