Rosemount 3095 - Autotuning

Rosemount Model 3095 Multivariable
™
Level Controller
3-4
TABLE 3-1. Level Controller Tasks
and Operation Modes.
OOS = Out-of-Service
MAN = Manual Mode
AUTO = Automatic Mode
ALL = All Modes
AUTOTUNING
The Model 3095 Level Controller is available with Rosemount’s
optimal tuning parameters for a level control loop without operator
interaction. The Autotuner algorithm is specified by the “CC” option
code in the level controller ordering table.
Improved loop tuning results in superior process control, reduced process
variability, an increase in loop performance, and extended control
element life. The Autotuner determines the optimal tuning parameters
after the user enters the required autotuning setup information.
Level Controller Parameter or Task Required Mode
Level Parameters MAN, OOS
Control Type and Action MAN, OOS
Setpoint Adjustment ALL
Setpoint Limits ALL
Setpoint Tracking ALL
Control Setup ALL
Control Gain ALL
Controller Output MAN, OOS
Autotuner Setup AUTO, MAN, OOS
Autotuner “Alpha” AUTO, MAN, OOS
Invoke Auto-tuning AUTO, MAN
Manual Output MAN
Mode Shed Configuration ALL
Local Operator Interface Units ALL
Local Operator Interface Slots ALL
Local Operator Interface Enable ALL
RTD Install ALL
Range Values ALL
Units Code ALL
Damping Values ALL
Sensor Trim MAN, OOS
DAC Trim OOS
Trim Recall MAN, OOS
Tag, Description, Date ALL
Final Assembly Part Numbers ALL
Materials of Construction MAN, OOS
Trim Recall MAN, OOS
Autotuning algorithm, which accurately determines the
