Rosemount 3095 - Unpacking the Level Controller; Becoming Familiar With the Level Controller

2-5
Level Controller Overview and Installation
UNPACKING THE LEVEL
CONTROLLER
The Level Controller arrives in either one or two shipping containers,
depending on the system ordered.
Level Controller
This box contains the Level Controller. If ordered, this package also
contains an RTD cable and optional mounting hardware. One Model
3095 Multivariable Level Controller Product Manual is included with
each order.
RTD Assembly (Optional)
This box contains the optional Series 68 or Series 78 RTD Assembly
and the Sensor Wiring Instruction Sheet.
When you unpack the Level Controller:
1. Place the shipping containers on a secure bench and open them,
taking care not to damage the contents.
2. Review the packing list to verify that all equipment was received.
3. Inspect the equipment and report any shipping damage to the
carrier.
BECOMING FAMILIAR
WITH THE LEVEL
CONTROLLER
Figure 2-1 on page 2-2 illustrates a typical Level Controller installation
site; Figure 2-4 shows the exploded view of the Model 3095 Level
Controller. Major components of the Level Controller system and the
Level Controller itself are identified in these figures.
