Rosemount 3144P - Page 38

Reference Manual
00809-0100-4021, Rev FB
August 2011
Rosemount 3144P
3-8
HART
Figure 3-4. 3144P Device Dashboard - Configure
Home
1 Overview
2 Configure
3 Service Tools
Configure
1 Guided Setup
2 Manual Setup
3 Alert Setup
3144 Wave 0_5 375 Menu Tree - Configure
Guided Setup
1 Configure Sensors
2 Calibrate Sensors
3 Configure Device
4 Configure Display
5 Config Hot Backup
6 Config Drift Alert
Sensor 1
1 Sensor 1 Temp
2 Sensor 1 Type
3 Sensor 1 Connection
4 Engineering Units
5 2-Wire Offset
6 Sensor 1 Damping
7 Serial Number
8 Upper Sensor Limit
9 Lower Sensor Limit
10 SensorMatching-CVD
SensorMatching-CVD
1 RO Value
2 A Value
3 B Value
4 C Value
5 Set CVD Coefficients

Manual Setup
1 Sensor 1
2 Sensor 2
3 Calculated Output
4 Diagnostics
5 Analog Output
6 Display
7 Device
8 HART
Sensor 2
1 Sensor 2 Temp
2 Sensor 2 Type
3 Sensor 2 Connection
4 Engineering Units
5 2-Wire Offset
6 Sensor 2 Damping
7 Serial Number
8 Upper Sensor Limit
9 Lower Sensor Limit
10 SensorMatching-CVD
Calculated Output
1 Differential Temperature
2 Average Temperature
3 First Good Temperature
Diagnostics
1 Hot Backup
2 Sensor Drift Alert
Analog Output
1 Primary Variable is
2 Param
3 Analog Output Value
4 Percent of Range
5 PV Configuration
6 Alarm/Sat Levels
Display
1 Displayed Variables
2 Decimal Places
3 Bar Graph
Device
1 Device Information
2 Security Switch
3 Terminal Temp Units
4 Open Sensor Holdoff
5 Noise Rejection
6 Reset Processor
HART
1 Polling Address
2 Requested Preamble
3 Burst Mode Setting
4 Burst Mode Option
5 Variable Mapping
SensorMatching-CVD
1 RO Value
2 A Value
3 B Value
4 C Value
5 Set CVD Coefficients

Differential Temperature
1 Differential Value
2 Differential Units
3 Differential Damping
Average Temperature
1 Average Value
2 Average Units
3 Average Damping
First Good Temperature
1 First Good Value
2 First Good Units
3 First Good Damping
Hot Backup
1 Hot Backup mode
2 Primary Variable is
3 Config Hot Backup
4 Reset Hot Backup
Sensor Drift Alert
1 Drift Alert Mode
2 Drift Alert Threshold
3 Drift Alert Damping
4 Drift Alert Eng. Units
5 Configure Drift Alert
PV Configuration
1 Primary Variable is
2 Upper Range Value
3 Lower Range Value
4 Minimum Span
Alarm/Sat Levels
1 High Sat Level
2 Low Sat Level
3 High Alarm Level
4 Low Alarm Level
Device Information
1 Tag
2 Date
3 Descriptor
4 Message
5 Final Assembly No.
Noise Rejection
1 Line Voltage Filter
2 Transient Filter
Variable Mapping
1 Primary Variable is
2 Second Variable is
3 Third Variable is
4 Fourth Variable is
5 Re-map Variables
