Section 2 Installation
Mechanical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . page 2-2
Electrical Installation with Integral Electronics . . . . . . . . page 2-10
Electrical Installation with Remote Electronics . . . . . . . . page 2-13
Pneumatic Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 2-17
IMPS 4000 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . page 2-18
SPS 4001B Connections . . . . . . . . . . . . . . . . . . . . . . . . . . page 2-18
Before installing this equipment, read the "Safety Instructions" for the wiring and installation
of this apparatus in Appendix A of this Instruction Manual. Failure to follow safety
instructions could result in serious injury or death.
The Hazardous Area Oxymitter 5000 and probe abrasive shield are heavy. Use proper
lifting and carrying procedures to avoid personal injury.
Install all protective equipment covers and safety ground leads after installation. Failure to
install covers and ground leads could result in serious injury or death.
