Hazardous Area Oxymitter 5000
2-16
Instruction Manual
IM-106-350C, Rev 2.2
July 2008
Install Interconnecting
Cable
NOTE
If interconnect cable was not purchased with the Hazardous Area Oxymitter
5000, consult the factory for the proper wire type and gauge.
1. Remove cover (17, Figure 9-4) from the junction box (24). Connect the
electronics end of the interconnecting cable (30) to the "FROM PROBE"
side of the terminal block (Figure 2-10).
2. Loosen screw (18, Figure 9-3), cover lock (19) and washer (20) at the
probe head. Remove cover (17).
3. See (Figure 2-10). Connect the heater power leads, the thermocouple
leads, and the oxygen signal leads of the interconnecting cable to the
terminal block. The cable leads are tagged for polarity. To avoid a shock
hazard, the heater power terminal cover must be installed.
4. Install covers (17, Figure 9-3 and Figure 9-4) and secure with captive
washers (20), cover locks (19), and screws (18).
If using an IMPS 4000 or an SPS 4001B, install it in a non-hazardous, explosive-free
environment.
