Reference Air Package
After the Hazardous Area Oxymitter 5000 is installed, connect the reference
air set to the Hazardous Area Oxymitter 5000. Refer to Figure 2-11.
Instrument Air (Reference Air): 68.95 kPa gage (10 psig) minimum, 1551.38
kPa gage (225 psig) maximum at 0.25 l/min (0.5 scfh) maximum; less than 40
parts per million total hydrocarbons. Regulator outlet pressure should be set
at 35 kPa (5 psi).
Figure 2-11. Air Set, Plant Air
Connection
38740030
Ref AirSet
263C152G01
1Flowmeter0.006-0.057scmh(0.2-2.0scfh) 771B635H02
2PressureGage0-103kPaGage(0-15psig) 275431-006
3CombinationFilter-Reg.0-207kPaGage(0-30psig) 4505C21G01
Note:Dimensionsareinmillimeters
withinchesinparentheses. All
pipingspecifiedinU.S.Standards.
1
2
3
122.17(4.81)
FlowSet
PointKnob
0.125-27NPT
Outlet
30.22
(1.19)
254
(10.0)
Drain
Valve
79.25( Max3.12)
215.90
(8.50)
Max
50.80
(2.0)
Mounting
Holes
81.03
( )Lg
for
7.92( )
Dia.
Through
Bolts
3.19
0.312
38.10
(1.50)
57.15(2.250)
SCHEMATICHOOKUP FORREFERENCE
AIRSUPPLY TOHAZARDOUS AREA
OXYMITTER5000PROBEHEAD
Outlet
0.25-18
NPT
Inlet
Instrument Air
69-1551kPaGage
(10-225psig)Max.
0.250in.or6mmO.D. Tubing
(SuppliedbyCustomer)
500VA
SERIAL NO.
TAGNO.
OXYMITTER5000
WATTS:VOLTS:
FUSE:LINEOUTPUT:
RosemountAnalyticalInc.
Solon,OH44139
85-264VAC48-62Hz
TM
800-433-6076
4-20 mA
R
5 Amps
TM
HART
SMARTFAMILY
Ref
2
3
1
ReplacementParts
