Rosemount Oxymitter 5000 - Electrical Installation with Remote Electronics

Instruction Manual
IM-106-350C, Rev 2.2
July 2008
2-13
Hazardous Area Oxymitter 5000
ELECTRICAL
INSTALLATION WITH
REMOTE ELECTRONICS
All wiring must conform to local and national codes.
NOTE
To maintain CE compliance, ensure a good connection exists between the
mounting flange bolts and earth.
Disconnect and lock out power before connecting the unit to the power supply.
Install all protective equipment covers and safety ground leads after installation. Failure to
install covers and ground leads could result in serious injury or death.
To meet the Safety Requirements of IEC 1010 (EC requirement), and ensure safe operation
of this equipment, connection to the main electrical power supply must be made through a
circuit breaker (min 10 A) which will disconnect all current-carrying conductors during a fault
situation. This circuit breaker should also include a mechanically operated isolating switch.
If not, then another external means of disconnecting the supply from the equipment should
be located close by. Circuit breakers or switches must comply with a recognized standard
such as IEC 947.
The probe and probe abrasive shield are heavy. Use proper lifting and carrying procedures
to avoid personnel injury.
To maintain explosion-proof protection, all cable entry devices and blanking elements for
unused apertures must be certified flameproof, suitable for the conditions of use and be
properly installed.
