Technical description
38 / 127
LCS operation panel
Pilot lamps
Service interval op-
erating hours
The indicator shows the operating hours
until the next service.
Service interval
date
The indicator shows the date of the next
service.
Software version
The indicator shows the current software
version.
Symbol Name Functional description
Symbol Name Functional description
Pump pressure
governor
The control displays the condition of the
pump pressure governor.
The pilot lamp has three switching condi-
tions:
• Green: pump pressure governor ac-
tive
• Orange: actual pump pressure devi-
ates from target pump pressure
• Grey: pump pressure governor inac-
tive
Priming pump
The control shows the status of the prim-
ing pump and the priming process.
The pilot lamp has three switching condi-
tions:
• Green: priming process successfully
ended, automatic mode active
• Orange: priming process being car-
ried out
• Grey: priming pump inactive
