Effectivity: 912 Series
Edition 1 / Rev. 0
d04053
page 45
May 01/2007
BRP-Rotax
INSTALLATION MANUAL
09167
Fig. 20
09166
Fig. 19
- ball joint, male
See Fig. 19.
Material/thickness of the exhaust components:
X 15CrNiSi 20,12 (DIN 1.4828) (stainless) a= 1 mm (0.039 in.)
- exhaust tube
See Fig. 20.
Material/thickness of the exhaust components:
X 15CrNiSi 20,12 (DIN 1.4828) (stainless) a= 1 mm (0.039 in.)
