Rotax 912 ULS 3 - Additional Operating Limits - 912 S;ULS; Engine Start, Fuel, and Auxiliaries; Bank Angle Limits

Effectivity: 912 Series
Edition 1 / Rev. 0
d04052
page 29
May 01/2007
BRP-Rotax
INSTALLATION MANUAL
en
g
ine from
serial
production
3
external
alternator
hydraulic
governor
vacuum
pump
centre of gravity in x-axis (mm) -316 -100 -276 -255
centre of gravity in y-axis (mm) -5 139 0 0
centre of gravity in z-axis (mm) -83 6 56 56
engine
version
2 / 4
engine
version
3
moment of inertia around
axis x1 - x1 (kg cm²)
11 100 11 600
moment of inertia around
axis y1 - y1 (kg cm²)
10 900 11 390
moment of inertia around
axis z1 - z1 (kg cm²)
17 400 18 200
09183
09182
exhaust system ........................ approx. 4,0 kg (8.8 lb)
oil radiator .......................................... 0,55 kg (1.2 lb)
engine mount ....................................... 2,0 kg (4.4 lb)
8.4) Centre of gravity of engine and standard equipment
See Fig. 2/3/4.
◆ NOTE: Dimensions to point of reference (P).
8.5) Moments of inertia
See Fig. 2/3/4.
