1.8 GENERAL
10 DOC01-V6ULB+
1.8 Certifications
CAN/CSA C22.2 No. 60601-1:14
CAN/CSA C22.2
No. 60601-1-6:11+AMD1:2015
CAN/CSA C22.2
No. 60601-2-52:11+AMD1:2017
ANSI/AAMI ES60601-1:2005/(R)2012 -
AND A1:2012, C1:2009/(R)2012 AND
A2:2010/(R)2012 (Consolidated text -
edition 3.1)
IEC60601-1-6:2006 + A1: 2013
IEC60601-2-52:2009+A1:2015
European CISPR 11 :2015+A1
:2016/EN 55011 :2016+A12017,
Class A, Group 1
1.9 Electrical specifications
Model
VersaTech 600 ULB
Insulation
Class II
Rated voltage
120/220/230/240 vac
Cycles
50/60 Hz
Maximum current
120V model
Without auxiliary
outlet: 4.5A
220/230/240V model
Without auxiliary
outlet 4.5A
Note that ULB+ model is a Class I device and must
be plugged in a grounded outlet. Connecting the
device to a supply network that has no grounding
terminal increases RISK OF ELECTRICAL SHOCK.
Electrical specifications suite
Model
VersaTech 600 ULB+
Insulation
Class I
Rated voltage
120/220/230/240 VCA
Cycles
50/60 Hz
Maximum current
120V model
With auxiliary outlet: 8.75 A
220/230/240V model
With auxiliary outlet: 6.25 A
Protection
IPX4
Duty cycle
10% maximum
(2 min. / 18 min.)
Maximum sound
pressure level
< 59.5 dBa
Scale accuracy
(when installed)
± 2% + 1 kg (2%+ 2 lb)
Min : 32 Kg (70 lb)
e: 0.5 Kg
1.10 Terms of use
Operating environment
Temperature
5 to 40 ˚C
Relative humidity
15% à 95%
(Non-condensing)
Atmospheric
pressure
70kpa to 106kpa
Storage environment
Temperature
-40 to 70 ˚C
Relative humidity
10% à 100%
(Non-condensing)
Atmospheric
pressure
70kpa to 106kpa
WARNINGS ON FEATURES AND SPECIFICATIONS
Ensure that the height of the bed frame is at a suitable height for entry/exit to
avoid the RISK OF FALLING, which could lead to SERIOUS INJURY.
Before fully lowering the mattress base from the nursing controls, ensure that no
part of the patient is sticking out from the mattress and that nothing is under the
bed platform, as this could result in SERIOUS INJURY AND/OR POTENTIAL
BREAKAGE.
Class I device are provided with functional ground.
