Rotec VersaTech 600 ULB - Foot Section Motor Replacement

6.10 REPAIR PROCEDURES
DOC01-V6ULB+ 57
6.10 Foot section motor replacement
Tools required :
• 9/16" wrench • Flathead screwdriver • Cutting pliers
Procedure:
1. Raise the bed to its highest position and apply the brakes.
2. Position platforms horizontally.
3. Unplug the power cord from the wall socket.
4. Using wire cutters, remove the cable ties securing the cables to the motor (A).
C
B
D
B
B
B
C
D
A
