Rotec VersaTech 600 ULB - Foot Section Angle Adjustment; Pole Holder

3.7 OPERATING INSTRUCTIONS
24 DOC01-V6ULB+
3.7 Foot section angle adjustment
When raised, the end of the foot section of the bed platform can be lowered as required.
To do this, simply lift the end of the foot section (step #1). The mechanism should unlock.
Then lower the foot section until it reaches the lock (step #2).
To return the foot section to the horizontal position, fully lower the thigh section using
the motorized controls and the foot section will lock back into the horizontal position.
3.8 IV Pole holder
Six (6) devices are located at the head of the structure, in three different sizes: 1/2, 7/8
and 1 inch diameter.
WARNINGS ON THE SOLUTE ROD HOLDER
 Do not use the Trendelenburg function when an IV holder is installed on the
bed, to avoid material damage and RISK OF INJURY to the patient.
Devices for
IV Pole holders (6)
1
2
