3.17 OPERATING INSTRUCTIONS
DOC01-V6ULB+ 35
3.17 Auxiliary output (optional)
If the bed is equipped with an auxiliary power socket, this is located under the footboard.
The voltage of the auxiliary socket is that of the mains supply, and the socket capacity
may be 2.5A or 5A, depending on the model.
This socket is connected to the unit's main power supply via an isolation transformer.
Unplugging the bed's wall power supply deactivates the output.
It is designed for connection to a maximum 600W air mattress pump. Exceeding the
current indicated on the plug marking may cause the circuit to break.
If the plug doesn't work, press the circuit-breaker reset button located near the power
cable inlet (at the head) to reconnect the circuit.
WARNINGS ON THE AUXILIARY SOCKET
Only connect medical-grade devices consuming 5A (120 VAC) / 2.5A
(220/230/240 VAC) or less to the auxiliary socket.
In practice, connecting an electrical device to the auxiliary socket leads to the
creation of an electromechanical system. This can lead to a reduced level of
safety.
Do not connect an extension lead or a multi-outlet socket to the bed's auxiliary
socket.
Do not use the auxiliary socket for life-sustaining equipment.
