6.13 REPAIR PROCEDURES
DOC01-V6ULB+ 63
6.13 CPR handle replacement
Tools required :
•7/16" wrench • Robertson screwdriver
Procedure:
1. Raise the bed to its
highest position and
apply the brakes.
2. Unplug the power cord
from the wall socket.
3. Locate the CPR handle.
4. Using a 7/16" wrench, loosen locknut (A).
5. Disengage the cable from the support and the lead from the handle and remove
the cable.
6. Unscrew the 4 screws (B) using the Robertson screwdriver and remove the
handle.
Lead
Support
To Next Page
