3.2 OPERATING INSTRUCTIONS
DOC01-V6ULB+ 19
3.2 Moving the unit
To move the unit, we recommend raising the base by at least 150mm (6") from its lowest
position, to facilitate access to the foot pedal. To operate the system, place the foot
pedal in one of three positions:
DIRECTIONAL
To engage the directional
mode and allow the right-
headed caster to roll in a
straight line:
Press on the green side of
the pedals.
NEUTRAL
To remove all restrictions
and allow the bed to roll
freely in all directions:
Position pedals
horizontally.
BRAKE
To apply the brakes and
bring the bed to a complete
stop:
Press the red side of the
pedals.
When the bed is heavily loaded, two people are recommended to move it.
WARNINGS ON THE SYNCHRONIZED BRAKE SYSTEM
Always apply the brakes after moving the bed or when a patient is on the bed, as
this could cause INJURY TO the patient when getting on and off the bed.
Always check that the brakes are engaged when attempting to move the bed.
