3.11 OPERATING INSTRUCTIONS
DOC01-V6ULB+ 27
3.11 Trapeze bar installation (optional)
Insert the trapeze bar into its receptacle, taking care to align the positioning stop with
its notch. Designed for Rotec trapezes bar.
Make sure the trapeze bar is correctly positioned by attempting to move it by turning it.
WARNINGS ON THE TRAPEZE BAR
Do not use the Trendelenburg function when a trapeze bar is installed on the bed,
to avoid MATERIAL BREAKAGE and the RISK OF INJURY to the patient.
NOTCH
FINAL
POSITION
POSITIONING STOP
