Rotec VersaTech 600 ULB - Nurse Call Port Replacement

6.4 REPAIR PROCEDURES
48 DOC01-V6ULB+
6.4 Nurse call port replacement
Tools required :
• Flat screwdriver • Cutting pliers
Procedure:
1. Raise the bed to its highest position and apply the brakes.
2. Unplug the power cord from the wall socket.
3. Using wire cutters, remove the cable ties securing the nurse call connector cable
to the chassis.
4. Remove the two screws shown.
5. Follow the cable and disconnect it by pressing the two locks.
6. Reverse the above steps to install the new nurse call.
7. Check that all controls are working properly before putting the bed back into
service.
