6.3 REPAIR PROCEDURES
DOC01-V6ULB+ 47
5. Lift the backrest and open the electrical box. See battery section.
6. Disconnect the white and black wires of the power cable from the junction boxes.
MAKE SURE THE BED IS UNPLUGGED.
7. Disconnect green wire from ground pole.
8. Remove power cord.
9. Reverse the above steps to install the new power cord. Be sure to replace the
power cord grounding lug underneath.
10. Check that all controls are working properly before putting the bed back into
service.
