6.10 REPAIR PROCEDURES
58 DOC01-V6ULB+
5. Disconnect the motor cable (A) by removing the lock (F) with a flathead
screwdriver, pressing down on both sides.
6. Using a 9/16" wrench, retain the 2 screws (C and D) and, using another 9/16"
wrench, loosen the nuts (B).
7. Reverse the above steps to install the new foot section motor.
8. Check that the foot section motor is working properly before putting the bed back
into service.
Lock (F)
