R5 SOLID AIS System
OPERATION
7000 118-200, C2 Page 28
The light sensor will automatically dim the backlight of the display depending on measured
input light to the sensor.
5 - ARROW KEYPAD and ENTER
The arrow keypad (< > and ∧ ∨ ) is used to navigate in menus, lists and edit fields. The
center button of the keypad is an ENTER button which is used to select the highlighted
choice in a menu, list or edit control.
6 - ESC
The ESC button is used to return to the previous screen or to cancel an edit change of a
data field.
7 - ALPHANUMERIC KEYS
These keys are used for entering text and numbers. To write a number in a numeric field,
press the key once. To write a character in a text field, press once for the character
associated with the key, twice for the second character and so on. When pressing twice
on key “1” when editing a text field, a popup view with special characters appears.
Choose the desired special character by using the ARROW KEYPAD and ENTER.
When a USB keyboard is used, the normal letters, numbers and special characters can be
used. Only American keyboard layout is supported.
8 - OPT
This button is an “Option key” which is only active in some of the dialogs. When pressed,
it gives the user a list of options that can be performed on the highlighted item. In e.g. the
Target List view the OPT button can be used to send an SRM to the highlighted target. In
the Main Menu view, the OPT button is used to quickly change navigational status. When
a USB keyboard is used, the ALT button of the keyboard corresponds to OPT button on
the R5 SOLID keypad.
If the OPT button is pressed for more than 5 seconds, the visual settings in the R5 SOLID
will be restored to default, i.e. LCD backlight, LED intensity and button backlight will all be
80% and day mode will be used.
9 - BACKSPACE
The BACKSPACE button is used to erase the character to the left of the marker in an edit
field.
4.2.1 Change Settings of a Parameter
Several of the views in the R5 SOLID contain parameters that can be edited. To edit a
parameter, select it by using the ARROW KEYPAD and press ENTER.
Then enter data in one of the following ways:
Numbers: Press the ALPHANUMERIC KEY that corresponds to each digit. To
delete a digit, press function key BACKSPACE. Some of the parameters are
decimal numbers. The OPT button can then be used to insert a decimal point.
Text: Press the ALPHANUMERIC KEY that corresponds to each character.
Press the key once for the first character, twice for the second character and so
on. Press the key “1” twice to, where allowed, bring up a menu for entering
special characters. To delete a character, press function key BACKSPACE.
When entering passwords both lower and upper case letters can be used. To
change between upper and lower case letters, press function key OPT and
choose “Caps Lock Off” or “Caps Lock On”.
