R5 SOLID AIS System
OPERATION
7000 118-200, C2 Page 35
LON SW
The longitude for the South West corner of the regional
area
4.4.6 Main Menu  Config  VHF Radio  LR Broadcast Settings
Parameter Name
Description
LR Broadcast Ch. 1
The first channel number for broadcasting long range
message 27. The message is sent every 6 minutes on
each channel so if both channels are configured a
message 27 will be broadcasted every 3 minutes. If this
parameter is set to zero no long range broadcast
transmissions will be sent on this channel.
LR Broadcast Ch. 2
The second channel number for broadcasting long
range message 27. The message is sent every 6
minutes on each channel so if both channels are
configured a message 27 will be broadcasted every 3
minutes. If this parameter is set to zero no long range
broadcast transmissions will be sent on this channel.
4.4.7 Main Menu  Config  Alarm
In this view all alarms can be configured to either “Enabled” or “Disabled”. When the
alarm is enabled, an active alarm will affect the external alarm relay, the buzzer in the
R5 SOLID and show a popup dialog in the display. When the alarm is set to disabled it
will not affect anything when the alarm becomes active. For more information about the
alarm view, refer to section 4.18 “Alarms”. For a list of all the alarms that can occur,
refer to section 7.3 “Troubleshooting with Alarm Messages.”
4.4.8 Main Menu  Config  Password
Parameter Name
Description
New User Password
Changes the user level password for the R5 SOLID.
The default user level password is “user”
New Admin Password
Changes the admin level password for the R5 SOLID.
The default admin level password is “admin”
Restore Code
It is possible to restore both user password and admin
password to the default values above with a secret
restore code.
To obtain the restore code, contact Saab
TransponderTech Support and be prepared to provide
the serial number of the transponder unit.
