28
English
Remove the strip of paper (Fig. 75).
Insert the packet of stirrers (Fig. 74).
Fig. 75
Fig. 74
Insert the second packet of stirrers and remove the paper.
7.3 Stirrer supply
Important
Use stirrers suited to automatic distribution, without
imperfections and conforming to the dimensions indicated
in sect. 2.4 Technical Data.
Press the locking clip and rotate the stirrer dispenser
towards the outside (Fig. 72).
Fig. 73
Remove the counterbalance bar (Fig. 73).
Fig. 72
