29
English
Fig. 76
Insert the counterbalance bar (Fig. 76).
Bring the stirrer dispenser to the starting position (Fig. 77).
Fig. 77
7.4 Cups supply
Important
This is a very delicate operation. Lack of respect for the
instructions provided at this point could cause serious
damage to the cup distributor.
The rotation of the cup column must be carried out with
the door open to be able to see the operation as it happens.
Open the door of the cup loader (Fig. 78).
Press key 1 (Fig. 60) of the CPU card to enter the
programming mode.
Keep key 3 (Fig. 60) pressed until the complete rotation
(180°) of the cup column (Fig. 79).
Warning
It is forbidden to introduce hands near or inside the cup
column during rotation.
Fig. 79
Fig. 78
