Saeco D.A. COMBISNACK - Dispensing Outlet Cleaning

53
English
Fig. 103
Screw the blocking ring clockwise (Fig. 102) and remove
the mixer case.
With a flat screwdriver, levering carefully, remove the fan
(Fig. 103).
Wash all the components with lukewarm water and pay
particular attention not to damage the fan. Carry out the
inverse procedure to assemble the components and connect
the dispensing hose correctly.
Fig. 102
10.2.8 Dispensing outlet
cleaning
By shifting the locking levers remove the dispensing outlet.
(Fig. 104).
Fig. 104
Fig. 105
Fig. 106
Remove the lower plate (Fig. 105).
Wash the dispensing outlet and the lower plate in lukewarm
water (Fig. 106).
Only after having dried them well, assemble the lower
plate onto the dispensing outlet.
