18
English
Fig. 35
Important
When a tray is connected to a different connector, the
products will be identified by a new selection number. The
vending machine self-configures whenever the vending
machine is switched on.
If a tray is linked to a different connector or the products
are loaded into a different spiral it is necessary to check
the values of the corresponding prices (see point 5.4).
Connect the tray to the fixed connector. When loading the
new products, take care that tray shifting is not hindered
by the connecting cable and prevent any possible damage
of the cable itself.
For this reason it is advisable to connect the tray to the
nearest upper connector, as shown in figure 35.
OK
NO
5.5 Plates and stickers
fitting.
Plates and stickers are contained in the CUSTOMER KIT.
Plates with codes and prices of snacks
On the front of the tray there is a compartment where the
plate with the code of the selected product and its price
are housed (Fig. 36).
The plates can be personalized by covering the
unnecessary areas with a marker until the desired number
appears.
Example
To obtain the code 42 corresponding to Lit. 800 cross
out the sectors as in figure 37.
Fig. 36
Fig. 37
Code Price
