Saeco D.A. COMBISNACK - Dispensing Arm Cleaning; Cup Bracket Cleaning

57
English
10.2.11Cup bracket cleaning
Lift the locking lever and remove the cup holder (Fig. 122).
Fig. 122
10.2.10Dispensing arm cleaning
Disconnect the hoses from the dispensing arm (Fig. 119).
Fig. 119
Fig. 120
Fig. 121
Disassemble the dispensing unit (Fig. 120).
Lift the locking lever and remove the mobile drip tray. (Fig.
121).
Wash all components with lukewarm water and reassemble
it proceeding in reverse order.
