Samsung HLS5087WX/XAA User Manual

8. MST33X9
No Item Range Default Remark
1 RED CUTOFF 0~255 127
2 GREEN CUTOFF 0~255 96
3 BLUE CUTOFF 0~255 127
4 PHASE 0~64 0
5 RED GAIN 0~255 202
6 GREEN GAIN 0~255 207
7 BLUE GAIN 0~255 202
8 PLLDIV 0~4096 857
9 PLLGAIN 0~31 1
10 CLPDLY 0~255 8
11 CLPDUR 0~255 8
12 HSOPW 0~255 24
13 SYNC_CTRL 0~255 64
14 SOGMID_CTRL 0~255 189
15 SEP_THR 0~255 32
16 PRECST 0~255 11
17 POSTCST 0~255 8
18 ADC_BWO 0~255 102
19 ADC_BW1 0~255 6
20 Test Pattern 0~8 0
Alignment & Adjustment
Samsung Electronics 3-11
