Alignment & Adjustment
3-12 Samsung Electronics
9. SDP51(M)
No Item Range Default Remark
1 Y_Offset 0~1023 0
2 Y_Gain 0~2047 512
3 NR_Zeromotion_MD 0~255 48 Gain control for Motion detecton
4 NR_Fullmotion_MD 0~255 96
5 NR_Zeromotion_MC 0~255 40 Gain control for Motion compensation
6 NR_Fullmotion_MC 0~255 80
7 VPP_ON 0~1 0 0 : VPP OFF , 1 : VPP ON
8 VPP_Gain 0~255 30 Gain Control
9 VPP_Coring 0~47 5
10 ST_Field_CNT 0~7 5
11 ST_Ver_Mot_Min 0~255 5 VM: vertical motion
12 ST_Ver_Mot_Max 0~255 64
13 ST_Def_Min 0~255 5
DF: default → normal
14 ST_Def_Max 0~255 64
15 ST_Ticker_Min 0~255 2 TD: ticker detection
16 ST_Ticker_Max 0~255 18
17 ST_2:2_Min 0~255 5 2:2 detection (normaly source 3:2)
18 ST_2:2_Max 0~255 64
19 Mo_Ver_Mot_Min 0~255 3
20 Mo_Ver_Mot_Max 0~255 12
21 Mo_Def_Min 0~255 2
22 Mo_Def_Max 0~255 12
23 Mo_Ticker_Min 0~255 32
24 Mo_Ticker_Max 0~255 64
25 Mo_2:2_Min 0~255 0
26 Mo_2:2_Max 0~255 0
27 Spatial_Angle_TH 0~255 300
0 : vertical interpolation(do not use directional information)
28 Ticker_Mode 0~3 3
0 : ALL OFF, 1 : interlace only, 2 : except film, 3 : ALL ON
29 Debuger_Mode 0~7 0
0: off, 1 : film, 2:Stop, 3:Motion, 4: Moving 5:judder, 6: ticker, 7: weigh
30 3:2_Mode 0~3 1
31 2:2_Mode 0~3 1
32 32_22 Combi 0~3 3
3 : ALL ON, 2 :film23 ON/film22 OFF, 1 : film23 OFF/film 22 ON, 0 :ALL OFF
33 3:2Count 0~255 10
34 2:2Count 0~255 40
35 TD_LINES 0~1023 180
36 CAPTION_AREA_UP 0~1023 30
37
CAPTION_AREA_DOWN
0~1023 180
