PCB Diagram
9-4 Samsung Electronics
9-2-3 Main Board Connector Pin
CN9000
Pin No. Pin Name
1 GND
2 GND
3 12VB
4 12VB
5 GND
6 SDA-M1
7 SCL-M1
8 GND
9 S5V
10 GND
11 70VB
12 GND
Pin No. Pin Name
1 -L_OUT
2 +L_OUT
3 -R_OUT
4 +R_OUT
CN803
Pin No. Pin Name
1 GND
2 KEY1
3 KEY2
4 GND
CN804
Pin No. Pin Name
1 IR
2 GND
3 S5V_MICOM
CN805
Pin No. Pin Name
1 S5V_MICOM
2 KEY-PWR
3 GND
4 LED_STB
5 LED_LAMP
6 LED_TIMER
CN9403
CN9400
Pin Name PIN No. Pin Name
STD5V 1 2 N.C
GND 3 4 S14.5V
STD5V 5 6 S_GND
GND 7 8 S14.5VB
POWER_SW 9 10 S_GND
5.7VB 11 12 5.7VB
GND 13 14 GND
12V_OPTION 15 16 12V_OPTION
GND 17 18 GND
12VB 19 20 12VB
GND 21 22 GND
GND 23 24 12VB
