Samsung HLS5087WX/XAA - Page 74

PCB Diagram
Samsung Electronics 9-5
CN651
PIN No. Pin Name PIN No. Pin Name PIN No. Pin Name
1 GND 17 TX_ANYNET 33 GND
2 NC 18 RX_ANYNET 34 NC
3 RX_GEMSTAR 19 NC 35 SIDE_SDET
4 TX_GEMSTAR 20 GEMSTAR_IR 36 SIDE_VDET
5 GND 21 GND 37 GND
6 USBAP 22 USB_VCC_CHECK 38 USBPWON-OFF
7 USBAN 23 NC 39 WOOFER_MUTE
8 NC 24 NC 40 SPDIF_HDMI
9 GND 25 NC 41 GND
10 12V_OPTION 26 GND 42 12V_OPTION
11 S5V_REAR 27 S5V_REAR 43 GND
12 D5V 28 D5V 44 GND
13 9VA 29 9VA 45 GND
14 GND 30 DDC_EEP_WP 46 NC
15 NC 31 NC 47
HDMI1_HPLUG_CTL
16 NC 32 SPDIF_OUT 48
HDMI2_HPLUG_CTL
CN600
PIN No. Pin Name PIN No. Pin Name PIN No. Pin Name
1 TMDS_TX0+ 9 TMDS_TX1+ 17 TMDS_TX2+
2 TMDS_TX0- 10 TMDS_TX1- 18 TMDS_TX2-
3 GND 11 GND 19 GND
4 TMDS_TXC+ 12 NC 20 DLP_SYNCVAL
5 TMDS_TXC- 13 NC 21 MD_nRESET
6 SCL_DDP 14 NC 22 GND
7 NC 15 LAMP_TXn_1 23 DDP_READY
8 NC 16 LAMP_Rx 24 PWRGOOD
Pin No. Pin Name
1 NC
2 S9V
3 LNA_ON_OFF
4 SPL_CTL1
5 GND
6 SPL_CTL2
CN7000
