CN9406
PIN No. Pin Name PIN No. Pin Name PIN No. Pin Name
1 MONITOR_R 33 nRESETO_D 65 MAIN_CVBS
2 MONITOR_L 34 NRSTO_IN 66 NC
3 GND 35 IN_SW1 67 DTV_CVBS
4 NC 36 MST_nINT 68 GND
5 NC 37 MST_RST 69 V2-DET
6 NC 38 NC 70 V1-DET
7 GND 39 GND 71 COMP2-DET
8 HDMI2-ID 40 S2-DET 72 COMP1-DET
9 HDMI1-ID 41 S1-DET 73 PCJACK-ID
10 M_TC_HS 42 SDA_IN 74 MAIN_VBI
11 M_TC_VS 43 SCL_IN 75 M_TC_DE
12 M_TC_PCLK 44 GND 76 GND
13 GND 45 M_TC_R(6) 77 M_TC_R(2)
14 M_TC_R(9) 46 M_TC_R(5) 78 M_TC_R(1)
15 M_TC_R(8) 47 M_TC_R(4) 79 M_TC_R(0)
16 M_TC_R(7) 48 M_TC_R(3) 80 GND
17 GND 49 GND 81 M_TC_G(3)
18 M_TC_G(9) 50 M_TC_G(6) 82 M_TC_G(2)
19 M_TC_G(8) 51 M_TC_G(5) 83 M_TC_G(1)
20 M_TC_G(7) 52 M_TC_G(4) 84 M_TC_G(0)
21 GND 53 GND 85 GND
22 M_TC_B(9) 54 M_TC_B(5) 86 M_TC_B(2)
23 M_TC_B(8) 55 M_TC_B(4) 87 M_TC_B(1)
24 M_TC_B(7) 56 M_TC_B(3) 89 M_TC_B(0)
25 M_TC_B(6) 57 GND 89 GND
26 GND 58 SIDE_R 90 GND
27 GND 59 SIDE_L 91 GND
28 GND 60 MAIN_R 92 GND
29 GND 61 MAIN_L 93 GND
30 GND 62 I2S_RX_MCLK 94 GND
31 I2S_RX_BCLK 63 I2S_RX_LRCLK 95 RX_RS232
32 I2S_RX_DATA 64
SUB_WOOFER_OUT
96 TX_RS232
PCB Diagram
9-6 Samsung Electronics
To Next Page
