1 - 2 WS80A Service Manual
Product Specifications
Physical
Dimensions
Height: 1,430 – 1,710mm (with monitor)
Width: 557mm
Depth: 791 – 860mm
Weight: 105.4kg (with monitor)
Weight: Approx. 130kg (with Safe Working Load)
Imaging
modes
2D-Mode
M-Mode
Color Doppler
Pulsed Wave (PW) Spectral Doppler
Continuous Wave (CW) Spectral Doppler
Tissue Doppler Imaging (TDI)
Tissue Doppler Wave (TDW)
Power Doppler (PD)
Directional Power Doppler (S-Flow)
Color M-Mode
Anatomical M mode
3D imaging Mode
4D imaging Mode
ElastoScan Mode
Gray Scale
256 (8 bits)
Focusing
Transmit focusing, maximum of eight points (four points simultaneously
selectable)
Digital dynamic receive focusing (continuous)
Probes
(Type BF / IPX7)
Linear Array
L3-12A, L5-13, LA2-9A, LA3-16A, LA3-16AI, LA4-18B
Convex
C2-6, CA1-7A, CA2-8A, CA2-9A, CA3-10A, CF4-9, SC1-6
Endocavity
E3-12A, EA2-11B, VR5-9
Phased Array
PA3-8B, PE2-4, PM1-6A
