Chapter 5. Product Structure 5 - 31
Rear Board
▌ Main Functions
It serves as In/Out Interface to external devices.
[Figure 5.12 Rear Board Block Diagram]
▌ Specification
• Rear Left
- DVI Patient Monitor Port(Image
Only)
- BW Video Out
- Audio Line Out
- S-Video Out
- Mic In
• Rear Right
- DVI Patient Monitor Port(Full-HD)
- Ext. Trigger In / Out
- LAN Port
- USB Port x4(A30 6Port)0
