▐ Power Connection Part
The power connection part is located at the bottom on the rear panel.
[Figure 1.10 Power Connection Part]
① Power switch: Supplies or blocks power to the entire system.
② Power inlet: For the power cable to connect to external power
③ Power outlet: Provides power to the external peripheral devices from the internal
power supply of the system.
④ Equipotential terminal: Must be connected to the equipotential bonding network in a
treatment room.
▐ Probe Holder
Probe holders are mounted at the left and right-hand sides of the control panel.
