1 - 20 WS80A Service Manual
USB to RS-232C Serial Cable
USB to Serial (RS-232C) Converter with FTDI Chipset (FTDI FT232BM Compatible)
NOTE
For more information about the Open Line Transfer, refer to
`Chapter 9. Measurements and Calculations’.
Foot Switch
– 3 Pedals HID Type
To configure the foot switch function, go to Utility > Setup > Peripherals > Foot Switch.
You can select one function from the following: Freeze, Update, Record, Print1, Save,
Store Clip, Volume Start, PD Mode, Color Mode, M Mode, PW Mode, CW Mode,
Elastoscan Mode, TDI Mode, TDW Mode, Biopsy, Save/Send, or Store Clip/Send.
WARNING
Foot Switch cannot be used in the operating room
Misc.
Flash Memory Media
NOTE
■ The system cannot recognize USB 1.1 flash memory. Remove the flash
memory from the console and equip again with an appropriate device.
■ Regarding file formats that are not ordinarily saved: Please check first to see if
it is possible to save the file format on a desktop PC before trying to save the
file on flash memory.
■ Do not use flash memory media which contain anti-virus programs or are
defective. Otherwise, the product may fail to work properly.
NOTE
■ The system cannot recognize USB 1.1 flash memory. Remove
the flash memory from the console and equip again with an
appropriate device.
■ Regarding file formats that are not ordinarily saved: Please
check first to see if it is possible to save the file format on a
desktop PC before trying to save the file on flash memory.
■ Do not use flash memory media which contain anti-virus
programs or are defective. Otherwise, the product may fail to
work properly
