PY Manual Copyright © 2006 SANYO DENKI AMERICA, Inc.
86
Current Command, Band Eliminate Filter #1
(Notch Filter)
IBEF
Remote Operator Mode:
0
Page:
7
Default Value:
1000 Hz
Function:
Tune
Setting Range:
200 to 1000 Hz
Description:
• The center frequency of the notch filter with the characteristics shown in the following figure is set for the
current command in the velocity loop.
dB
Gain
.62 f
n
f
n
1.62
f
n
-3dB
0dB
frequency
(Hz)
