KY7-WU380000

-83-

Electrical Parts List

ASSEMBLED BOARDS

!A2000 655 002 8204 ASSY,PWB,AV KY7AC

!A690 655 002 8198 ASSY,PWB,LA KY7AC

!A200 655 004 9858 ASSY,PWB,NETWORK KY7AF

!A600 655 003 1174 ASSY,PWB,POWER KB8AC

!A630 655 003 1167 ASSY,PWB,FILTER KB8AC

!A100 655 005 0588 ASSY,PWB,MAIN KY7AF

!A2900 655 003 4380 ASSY,PWB,R/C KY7AE

!A4800 655 003 4373 ASSY,PWB,TEMP. KY7AE

OUT OF CIRCUIT BOARD

!L901 652 003 2767 CORE,CLAMP

945 023 4959 CORE,CLAMP

!LF901 645 091 5765 UNIT,NOISE FILTER

!LP900 610 333 9740 COMPL,OPT LMP-KM6AC

!A901 645 093 3134 UNIT,BALLAST+CV

!FN901 645 091 3693 MOTOR,FAN DC 2.40W

!FN902 645 091 3693 MOTOR,FAN DC 2.40W

!FN903 945 079 2145 MOTOR,BLW DC 2.76W

!FN904 645 093 1345 MOTOR,BLW DC 3.96W

!FN905 645 095 8960 MOTOR,BLW DC 1.92W

!FN907 645 095 8953 MOTOR,BLW DC 1.92W

K10A1 312 073 0406 SPECIAL SCREW

K10A2 312 073 0406 SPECIAL SCREW

K10B1 312 073 0406 SPECIAL SCREW

K10B2 312 073 0406 SPECIAL SCREW

K40A1 312 073 0406 SPECIAL SCREW

K40A2 312 073 0406 SPECIAL SCREW

SP901 652 002 3055 SPEAKER,8

652 002 4397 SPEAKER,8

!SW902 945 048 3159 SWITCH,THERMAL(100DEG)

A2000 655 002 8204 ASSY,PWB,AV KY7AC

CAPACITOR

C2031 303 370 1510 CERAMIC 0.1U K 50V

303 367 0410 CERAMIC 0.1U K 50V

C2061 303 157 3614 CERAMIC 100P J 50V

C2062 303 157 3614 CERAMIC 100P J 50V

RESISTOR

R2001 301 260 4115 MT-GLAZE 75 JA 1/3W

R2003 301 150 6014 MT-GLAZE 0.000 ZA 1/10W

301 105 7912 MT-GLAZE 0.000 ZA 1/16W

R2008 301 150 6014 MT-GLAZE 0.000 ZA 1/10W

301 105 7912 MT-GLAZE 0.000 ZA 1/16W

R2011 301 260 4115 MT-GLAZE 75 JA 1/3W

R2012 301 150 6014 MT-GLAZE 0.000 ZA 1/10W

301 105 7912 MT-GLAZE 0.000 ZA 1/16W

R2021 301 260 4115 MT-GLAZE 75 JA 1/3W

R2022 301 150 6014 MT-GLAZE 0.000 ZA 1/10W

301 105 7912 MT-GLAZE 0.000 ZA 1/16W

R2031 301 255 6513 MT-GLAZE 100 JA 1/10W

R2051 301 150 5819 MT-GLAZE 100K JA 1/10W

R2052 301 150 5819 MT-GLAZE 100K JA 1/10W

R2056 301 150 5819 MT-GLAZE 100K JA 1/10W

R2057 301 150 5819 MT-GLAZE 100K JA 1/10W

R2061 301 255 6513 MT-GLAZE 100 JA 1/10W

R2062 301 255 6513 MT-GLAZE 100 JA 1/10W

R2063 301 150 5819 MT-GLAZE 100K JA 1/10W

R2064 301 150 5819 MT-GLAZE 100K JA 1/10W

R2065 301 150 5819 MT-GLAZE 100K JA 1/10W

R2066 301 150 5819 MT-GLAZE 100K JA 1/10W

COIL

L2001 945 086 7461 FILTER,EMI 100MHZ

L2011 945 086 7461 FILTER,EMI 100MHZ

L2021 945 086 7461 FILTER,EMI 100MHZ

L2031 945 086 7461 FILTER,EMI 100MHZ

L2051 945 086 7454 FILTER,EMI 50MHZ

L2052 945 086 7454 FILTER,EMI 50MHZ

L2056 945 086 7454 FILTER,EMI 50MHZ

L2057 945 086 7454 FILTER,EMI 50MHZ

L2061 945 086 7454 FILTER,EMI 50MHZ

L2062 945 086 7454 FILTER,EMI 50MHZ

L2063 945 086 7454 FILTER,EMI 50MHZ

L2064 945 086 7454 FILTER,EMI 50MHZ

DIODE

D2031 307 221 7119 ZENER DIODE UDZS-TE-1712B

307 223 0514 ZENER DIODE 02DZ12Y(TPH3)

408 063 1802 ZENER DIODE MM3Z12B

MISCELLANEOUS

K20A 645 089 9041 SOCKET,DIN 4P

952 001 4740 SOCKET,DIN 4P

K20B 945 068 3740 JACK,RCA-3

952 001 5655 JACK,RCA-3

K20C 945 006 4792 JACK,PHONE D3.6

952 001 0070 JACK,PHONE D3.6

952 001 0971 JACK,PHONE D3.5

K20D 945 006 4792 JACK,PHONE D3.6

952 001 0070 JACK,PHONE D3.6

952 001 0971 JACK,PHONE D3.5

K20E 945 006 4792 JACK,PHONE D3.6

952 001 0070 JACK,PHONE D3.6

952 001 0971 JACK,PHONE D3.5

SC2001 945 076 3503 SURGE-ABSORBER

SC2011 945 076 3503 SURGE-ABSORBER

SC2021 945 076 3503 SURGE-ABSORBER

SC2031 945 076 3503 SURGE-ABSORBER

SC2051 945 076 3503 SURGE-ABSORBER

SC2052 945 076 3503 SURGE-ABSORBER

SC2056 945 076 3503 SURGE-ABSORBER

SC2057 945 076 3503 SURGE-ABSORBER

SC2058 945 076 3503 SURGE-ABSORBER

SC2059 945 076 3503 SURGE-ABSORBER

SC2061 945 076 3503 SURGE-ABSORBER

SC2062 945 076 3503 SURGE-ABSORBER

A690 655 002 8198 ASSY,PWB,LA KY7AC

SW901 945 063 5176 SWITCH,PUSH 2P-2TX3

A200 655 004 9858 ASSY, PWB,NETWORK KY7AF

INTEGRATED CIRCUIT

IC8801 410 732 2805 IC PIC18F67J60-I/PT-KY7AF

CAPACITOR

C8801 303 409 3426 CERAMIC 0.1U K 16V

303 453 8610 CERAMIC 0.1U K 16V

303 453 8917 CERAMIC 0.1U K 16V

C8802 403 455 1012 CERAMIC 1U K 10V

Key No. Part No. Description Key No. Part No. Description

Note: Parts order must contain Chassis No., Part No., and Descriptions.
