Sanyo PLC-WU3800 Service Manual

Key No. Part No. Description Key No. Part No. Description
KY7-WU380000
Electrical Parts List
-84-
303 433 1112 CERAMIC 1U K 10V
C8806 303 409 3426 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 453 8917 CERAMIC 0.1U K 16V
C8807 303 314 6410 CERAMIC 7P D 50V
C8808 303 314 6410 CERAMIC 7P D 50V
C8809 303 409 3426 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 453 8917 CERAMIC 0.1U K 16V
C8810 303 409 3426 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 453 8917 CERAMIC 0.1U K 16V
C8811 303 409 3426 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 453 8917 CERAMIC 0.1U K 16V
C8812 303 409 3426 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 453 8917 CERAMIC 0.1U K 16V
C8814 303 409 3426 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 453 8917 CERAMIC 0.1U K 16V
C8815 303 409 3426 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 453 8917 CERAMIC 0.1U K 16V
C8817 303 409 3426 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 453 8917 CERAMIC 0.1U K 16V
C8818 303 409 3426 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 453 8917 CERAMIC 0.1U K 16V
C8819 303 409 3426 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 453 8917 CERAMIC 0.1U K 16V
C8820 303 409 3426 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 453 8917 CERAMIC 0.1U K 16V
C8821 303 409 3426 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 453 8917 CERAMIC 0.1U K 16V
RESISTOR
R8039 301 341 0616 MT-GLAZ 49.9 FA 1/16W
R8049 301 341 0616 MT-GLAZE 49.9 FA 1/16W
R8059 301 341 0616 MT-GLAZE 49.9 FA 1/16W
R8069 301 341 0616 MT-GLAZE 49.9 FA 1/16W
R8801 301 224 9316 MT-GLAZE 1K JA 1/16W
R8802 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R8804 301 225 1210 MT-GLAZE 4.7K JA 1/16W
R8805 301 224 9316 MT-GLAZE 1K JA 1/16W
R8806 301 224 9316 MT-GLAZE 1K JA 1/16W
R8807 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R8808 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R8814 301 224 9415 MT-GLAZE 1M JA 1/16W
R8816 301 264 6511 MT-GLAZE 2.2K FA 1/10W
R8833 301 229 3913 MT-GLAZE 180 JA 1/16W
R8837 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R8838 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R8839 301 229 3913 MT-GLAZE 180 JA 1/16W
R8840 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R8841 301 224 9019 MT-GLAZE 10K JA 1/16W
R8843 301 224 9019 MT-GLAZE 10K JA 1/16W
R8844 301 224 9019 MT-GLAZE 10K JA 1/16W
R8846 301 224 8913 MT-GLAZE 100K JA 1/16W
R8850 301 253 3712 MT-GLAZE 0.000 ZA 1/4W
R8881 301 224 9019 MT-GLAZE 10K JA 1/16W
COIL
L8801 945 068 8318 FILTER,EMI 100MHZ
L8806 945 041 1978 INDUCTOR,330 OHM
L8835 645 100 9340 IMPEDANCE,120 OHM P
L8836 645 100 9340 IMPEDANCE,120 OHM P
MISCELLANEOUS
K9602 645 093 6760 TRANS,PULSE
652 003 2743 TRANS,PULSE
X8802 945 083 7556 OSC,CRYSTAL 25.0MHZ
A600 655 003 1174 ASSY,PWB,POWER KB8AC
TRANSISTOR
Q611 305 217 6600 TR 2SK3934
405 226 8807 TR 2SK3934(STA4,Q,M)
Q612 305 217 6600 TR 2SK3934
405 226 8807 TR 2SK3934(STA4,Q,M)
Q621 305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9915 TR 2SC3928A1S
Q622 305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9915 TR 2SC3928A1S
Q641 305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9915 TR 2SC3928A1S
Q642 305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9915 TR 2SC3928A1S
Q643 305 217 6600 TR 2SK3934
405 226 8807 TR 2SK3934(STA4,Q,M)
Q651 305 147 2218 TR 2SA1037AK-S-T146
405 220 3016 TR ISA1235AC1F
305 134 5928 TR 2SA1037AK-T146-R
405 220 3115 TR ISA1235AC1E
305 173 9717 TR 2SA1235A1F
305 173 9618 TR 2SA1235A1E
Q661 305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9915 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC621 409 690 7918 IC FA5550N
IC631 309 653 7405 IC MR4010-7101
IC671 409 692 2515 IC TA76L431FB
CAPACITOR
C611 304 084 6300 CERAMIC 1000P K 1K
303 222 1316 CERAMIC 1000P K 1K
C612 304 084 6300 CERAMIC 1000P K 1K
303 222 1316 CERAMIC 1000P K 1K
C613 303 451 4119 MT-POLYEST 1U K 450V
C614 303 451 4119 MT-POLYEST 1U K 450V
C615 404 115 2704 ELECT 330U M 420V
404 115 6306 ELECT 330U M 420V
C621 303 336 3510 CERAMIC 0.47U K 16V
C622 304 091 4504 CERAMIC 0.047U K 50V
C623 304 090 1207 CERAMIC 0.01U K 50V
C625 304 090 1108 CERAMIC 1000P K 50V
C626 303 396 9613 CERAMIC 1U K 25V
403 478 5912 CERAMIC 1U K 25V
C627 304 091 3309 CERAMIC 2200P K 50V

Sanyo PLC-WU3800 Specifications

General

Matrix size	0.59 \
Projection distance	0.99 - 12.1 m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	40 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	±40 °
Audio input	2
Aspect ratio	16:10
Network ready	Yes
Power supply type	AC
Dimensions (WxDxH)	335.7 x 257.5 x 93.6 mm
Connectivity technology	Wired
Focus	Manual
Digital zoom	16 x
Focal length range	19.2 - 30.2 mm
Noise level	35 dB
Noise level (economic mode)	31 dB
Dot clock scanning frequency	140 MHz
Lamp type	NSHA
Lamp power	275 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	3000 h
DVI port	No
Composite video in	-
Serial interface type	RS-232
USB 2.0 ports quantity	0
Supported video modes	1080i, 1080p, 720p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	White
AC input voltage	100 - 240 V
Power consumption (standby)	0.7 W
Power consumption (typical)	317 W
Power consumption (PowerSave)	280 W
Cables included	VGA

Weight and Dimensions

Depth	257.5 mm
Width	335.7 mm
Height	93.6 mm
Weight	3500 g
