14
Part Names and Functions
Spotlight
Pointer Function
Pointer
LaserLightWindow
SignalEmissionIndicator
Laser Pointer Function
LASERbutton
PRESENTATIONPOINTER
button
MENUbutton
NOSHOWbutton
This remote control emits a laser beam from the laser light window. Press the LASER button to activate the
laserpointer.Thesignalemissionindicatorlightsredandtheredlaserbeamisemitted.IftheLASERbuttonis
pressedformorethanoneminuteorifitisreleased,thelaserlightgoesoff.
ThelaseremittedisaClassIIlaser.Donotlookintothelaserlightwindoworpointthelaserbeamatyourselfor
otherpeople.Thefollowingisthecautionlabelforthelaserbeam.
CAUTION: Useofcontrols,adjustmentsorperformanceofproceduresotherthanthosespecifiedhereinmay
resultinhazardousradiationexposure.Neverlookdirectlyintothelaserlightwindowwhilealaser
isemitted,otherwiseeyedamagemayresult.
Thecautionlabelisputontheremotecontrol.
You can move the Spotlight or Pointer of the projector with the remote control to emphasize a part of the
projectedimage.
Press and hold the MENU and NO SHOW buttons
for more than 10 seconds to activate the Pointer
function.(TheLaserpointerhasswitchedtothePointer
function.)
1
Press the LASER button on the remote control
pointing toward the projector.The Spotlight orPointer
is displayed on the screen with the LASER button
lightinggreen.ThenmovetheSpotlightorPointerwith
the PRESENTATION POINTER button. If the LASER
button does not light green and continues to emit a
laser beam, try the abovementioned procedure until
theLASERbuttonlightsgreen.
2
TocleartheSpotlightorPointeroutthescreen,press
the LASER button pointing toward the projector and
seeiftheLASERbuttonlightingisturnedoff.
To switch to the Laser pointer again, press and hold
the NO SHOW and MENU buttons for more than 10
seconds or slide the RESET/ON/ALL-OFF switch to
“RESET”andthento“ON”.
WhenyouresetthePointerfunction,theremotecontrol
codewillbereset,aswell.
3
Note:
•You can choose the size of Spotlight (Large/Middle/
Small) and the pattern of Pointer (Arrow/Finger/Dot) in
theSettingMenu.See“Pointer”onpage53.
Press and hold the MENU
and NO SHOW buttons for
morethan10seconds.
PRESENTATIONPOINTER
button
After the Laser pointer has
switchedto the Pointer,use
the LASER button as the
Pointer function ON-OFF
switch. Press the LASER
button pointing toward the
projector and see if it lights
green.
