Installation
Connecting to a Computer
SD
KB3AC
Cables used for connection
•VGACable(MiniD-sub15pin)*
•DVI-VGACable
•DVICable
•USBCable
•AudioCables
(*Onecableissupplied;othercablesarenotsuppliedwiththeprojector.)
ExternalAudioEquipment
DVI-VGA
cable
USBcable
Audiocable
(stereo)
USBportAudioOutput
USB
COMPUTER/
COMPONENT
AUDIOIN
AUDIOOUT
(stereo)
AudioInput
COMPUTERIN1
DVI-I
Notes:
•Input sound to the COMPUTER/COMPONENTAUDIOIN
terminal when using the COMPUTER IN 1/DVI-I and the
COMPUTERIN2/COMPONENTINterminalasinput.
 •When theAUDIO OUT is plugged-in, the projector's built-in
speakerisnotavailable.
 •USBcableconnectionisneededwhenoperatingthecomputer
withtheremotecontrolorusingthePAGE▲▼buttonsonthe
remotecontrol.
Monitor
Output
COMPUTERIN2/
COMPONENT
VGAcable
MONITOR
OUT
Audiocable
(stereo)
Unplug the power cords of both the
projector and external equipment
fromtheAC outlet before connecting
cables.
VGAcable
Monitor
Output
Monitor
Input
DVI
cable
Monitor
Output
Downloaded From projector-manual.com Sanyo Manuals

Sanyo PLC-XU115 Specifications

General

Projection distance	0.93/11.47 m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-40 - 40 °
I/O ports	SD Card Slot
Audio input	1
Aspect ratio	4:3
Special features	Soft Carry Bag
Networking features	Ethernet & Wireless
F-number (relative aperture)	1.7
Lamp type	NSH
Lamp power	275 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Dot clock scanning frequency	140 MHz
Analog signal format system	NTSC, PAL, SECAM
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (typical)	266 W

Weight and Dimensions

Package weight	3500 g
