Sanyo PLC-XU115 User Manual

75
Terminal : Mini DIN 8-PIN
SERVICE PORT CONNECTOR
Vcc
-Data
+Data
Ground
1
2
3
4
2
3 4
1

COMPUTER IN 2 /COMPONENT IN /MONITOR OUT (ANALOG)
Terminal: Analog RGB (Mini D-sub 15 pin)
5
1
2
34
10
9 678
15
14
13
11
12
Configurations of Terminals
RX–
TX+
TX–
RX+
2
3
4
8 7 6 5 4 3 2 1
5
6
7
8
1
USB CONNECTOR (Series B)
LAN TERMINAL
-----
-----
----------
DVI-I TERMINAL (DIGITAL/ANALOG)
1
9
17
2
10
18
3
11
19
4
12
20
5
13
21
6
14
22
7
15
23
8
16
24
C1
C2
C3
C5
C4
T.M.D.S.Data2–
NoConnect
T.M.D.S.Data2+
NoConnect
T.M.D.S.Data2Shield
DDCClock
DDCData
Noconnect
1
5
2
4
3
6
7
8
T.M.D.S.Data1–
NoConnect
T.M.D.S.Data1+
NoConnect
T.M.D.S.Data1Shield
+5VPower
Ground(for+5V)
HotPlugDetect
9
13
10
12
11
14
15
16
T.M.D.S.Data0–
NoConnect
T.M.D.S.Data0+
NoConnect
T.M.D.S.Data0Shield
T.M.D.S.ClockShield
T.M.D.S.Clock+
T.M.D.S.Clock–
17
21
18
20
19
22
23
24
AnalogRedInput
AnalogGround(R/G/B)
AnalogGreenInput
AnalogHoriz.sync
AnalogBlueInput
C1
C5
C2
C4
C3
1
2
3
4
5
8 7 6
Appendix
Red(R/Cr)Input/ROutput 
Ground(Horiz.sync.)
Green(G/Y)Input/GOutput
-----
Blue(B/Cb)Input/BOutput
Ground(Red)
Ground(Green)
Ground(Blue)
1
5
2
4
3
6
7
8
+5VPower/---
Horiz.sync.Input(CompositeH/Vsync.)
Ground(Vert.sync.)
DDXData/---
Ground
Vert.sync.
DDCClock / ---
9
13
10
12
11
14
15
RXD
-----
-----
GND
-----
-----
-----
1
2
3
4
5
6
7
8
TXD
Downloaded From projector-manual.com Sanyo Manuals

Sanyo PLC-XU115 Specifications

General

Projection distance	0.93/11.47 m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-40 - 40 °
I/O ports	SD Card Slot
Audio input	1
Aspect ratio	4:3
Special features	Soft Carry Bag
Networking features	Ethernet & Wireless
F-number (relative aperture)	1.7
Lamp type	NSH
Lamp power	275 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Dot clock scanning frequency	140 MHz
Analog signal format system	NTSC, PAL, SECAM
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (typical)	266 W

Weight and Dimensions

Package weight	3500 g
