Sanyo PLC-XU115 User Manual

16
Part Names and Functions
Adjustable Feet
Toensuresafeoperation,pleaseobservethefollowingprecautions:
 ● Usetwo(2)AAAorLR03typealkalinebatteries.
 ● Alwaysreplacebatteriesinsets.
 ● Donotuseanewbatterywithausedbattery.
 ● Avoidcontactwithwaterorliquid.
 ● Donotexposetheremotecontroltomoistureorheat.
 ● Donotdroptheremotecontrol.
 ● Ifthebatteryhasleakedontheremotecontrol,carefullywipethecasecleanandinstallnewbatteries.
 ● Riskofanexplosionifbatteryisreplacedbyanincorrecttype.
 ● Disposeofusedbatteriesaccordingtotheinstructions.
Pressthelid
downwardandslideit.
Openthebattery
compartmentlid.
Installnewbatteries
intothecompartment.
Replacethe
compartmentlid.
Two AAA size
batteries
Forcorrectpolarity
(+and–),besure
batteryterminalsare
incontactwithpinsin
compartment.
1 2 3
Point the remote control toward the projector (Infrared
Remote Receiver) when pressing the buttons. Maximum
operating range for the remote control is about 16.4'(5 m)
and60degreesinfrontoftheprojector.
Remote Control Operating Range
Remote Control Battery Installation
Projectionanglecanbeadjustedupto8.9degreeswiththe
adjustablefeet.
Liftthefrontoftheprojectorandpullthefeetlocklatcheson
bothsideoftheprojectorupward.
Releasethefeetlocklatchestolocktheadjustablefeetand
rotatetheadjustablefeettoaproperheight,andtilt.
Keystone distortion can be adjusted automatically with the
Autosetupfunctionormanuallybyusingtheremotecontrol
orthemenuoperation(seepages26,47-48).
AdjustableFeet FeetLockLatches
16.4'
(5m)
30°
Remotecontrol
30°
Downloaded From projector-manual.com Sanyo Manuals

Sanyo PLC-XU115 Specifications

General

Projection distance	0.93/11.47 m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-40 - 40 °
I/O ports	SD Card Slot
Audio input	1
Aspect ratio	4:3
Special features	Soft Carry Bag
Networking features	Ethernet & Wireless
F-number (relative aperture)	1.7
Lamp type	NSH
Lamp power	275 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Dot clock scanning frequency	140 MHz
Analog signal format system	NTSC, PAL, SECAM
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (typical)	266 W

Weight and Dimensions

Package weight	3500 g
