150 Operating Instructions Combics Indicators
Menu Structure
setup /unicom
Off*
WP-2 Weighing platform 2 (Combics 2 only)
RS-232
SBI standard
SBI trade version (for legal metrology)
xBPI-232*
Menus 1.1 to 1.8 same as for WP1
Calibration/Adjustment 1.9
Ext. calibration/adjustment; default weight 1.9.1*
External calibration/adjustment;
weight can be selected (1.18.1) 1.9.3
Internal cal./adj. 1.9.4
No function when you press the J key 1.9.10
Menus 1.10 to 9.1 same as for WP1
ADC-232
Menus 1.1 to 9.1 same as for WP1
RS-485*
IS-485 Connect Sartorius IS weighing platform
Menus 1.1 to 1.8 same as for WP1
Calibration/Adjustment 1.9
Ext. calibration/adjustment; default weight 1.9.1*
External calibration/adjustment;
weight can be selected (1.18.1) 1.9.3
Internal cal./adj. 1.9.4
No function when you press the J key 1.9.10
Menus 1.10 to 9.1 same as for WP1
ADC-485
Menus 1.1 to 9.1 same as for IS-485
dat.prot. Data protocol
SBI SBI standard version*
Menus 5.1 to 9.1 same as for COM1
BPI-232 XBPI-232
BPI-485 XBPI-485
0 to 31 Network address: Selectable from 0 to 31
SMA SMA interface function
Menus 5.1 to 5.6 same as for COM1
profibus XBPI-485
Address 0 to 126 Addresses 0 to 126 can be selected
App/Dat
NO No*
YES Yes, transfer application data
ether Ethernet
SRC. IP Source IP: 192.168.0.1*
src.name Source name (max. 16 characters)
lis.port List port: 49155
subnet Subnet mask: 255.255.255.0
GATEW.IP Gate IP: 0.0.0.0*
DEST. IP Destination IP: 0.0.0.0*
DEST.POR Destination port: 49155*
protoc. Protocol
TCP*
UDP
mode
SBI-SRV (server)
Data output (manual/automatic) 6.1
Manual without stability 6.1.1
Manual after stability 6.1.2*
Protocol printout 6.1.7
Data output: Line format 7.2
For raw data: 16 characters 7.2.1
For other applications:
22 characters 7.2.1*
Data output: Sign format 7.3
Plus sign deactivated 7.3.1
Plus sign activated 7.3.2*
SBI-C/S (client)
Data output (manual/automatic) 6.1
Manual without stability 6.1.1
Manual after stability* 6.1.2
Automatic without stability 6.1.4
Automatic with stability 6.1.5
Protocol printout for
computer (PC) 6.1.7
