68 Cubis MSE Operating Instructions
Data Interfaces
Data Output
You can define the data output parameter so that output is activated either when
a print command is received or automatically synchronized with the display or at
defined intervals (see application programs and autoprint settings)�
Data Output by Print Command The print command can be transmitted by pressing P or by a software
command (EscP)�
Automatic Data Output In autoprint mode, data is output to the data interface port without an extra print
command� You can have synchronized data output automatically at defined display
update intervals, with or without the stability parameter� The interval time depends
on the balance operating status and balance type�
If the automatic data output is activated in the Device Configuration, it starts
immediately after the balance is turned on� You can also configure whether the
automatic data output can be stopped and started by pressing the P key�
Data Output Formats
You can output the values displayed in the line for measured values and weight
units with or without an ID code� Configure this output parameter in the Device
Parameters menu (Menu > Device parameters > Configure data output > Line
format)�
Example: Output Without an ID Code + 253 pcs 16 characters are printed
Example: Output With an ID Code Qnt + 253 pcs 22 characters are printed
Data Output Format with 16 Characters
Display segments that are blank are output as spaces�
Display values without a decimal point are printed without a decimal point�
The type of character that can be printed depends on the character’s position�
Normal Operation
Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
+ A A A A A A A A A * E E E CR LF
or – � � � � � � � � � � * * *
or * * * * * * * * * *
*: Space CR: Carriage return
A: Displayed characters LF: Line feed
S: Characters for the unit
